3M Duct Wrap 615+, Concrete Wall, Internal or External Fire

Duct (up to 1200 x 1200mm) through a fire-rated concrete, masonry, AAC or Speedpanel wall. Protection from internal or external fire. 3M Duct Wrap 615+ single layer for duct and double layer adjacent to penetration (third layer of 150mm required for 120mins). Plasterboard or Glasroc collar with fillet of 3M Fire Barrier CP25WB sealant. FRR -/120/120

Products

Details

System ID #: 498
Max Fire Rating: 120 mins
Max Thermal Rating: 120 mins
Size: Up to 1200mm wide x 1200mm high

System products available for purchase

Buy products

Associated Products & Downloads

Below are the downloads available. Please tick the ones you would like to receive and complete your details and select how you would like the files delivered to you. Alternatively you can click on the individual download name to view it now.

  Select All
  System diagram
  3M Duct Wrap 615+ Concrete Wall Tech Drawing
  3M Duct Wrap 615+ Access Door Design Specification Sheet
  3M Duct Wrap 615+ BRANZ FAR 4812 AS1530.4
  3M Duct Wrap 615+ CSIRO FCO-3273 AS1530.4

3M™ Fire Barrier Duct Wrap 615+
  Duct Wrap 615 Description
  3M Fire Barrier Duct Wrap 615+ Data Sheet
  3M Fire Barrier Duct-Wrap 615+ Design Spec Sheet Hatch
  3M Fire Barrier Duct-Wrap 615+ Multi-Layer System Installation Guide
  3M Fire Barrier Duct-Wrap 615+ Single Layer System Installation Guide
  3M Fire Barrier Duct Wrap 615+ Regulatory Data Sheet
  Duct Wrap 615+ Safety Data Sheet
  3M Duct Wrap 615 BRANZ FAR 4812 AS1530.4 Fire Certificate
  3M Duct Wrap 615+ BRANZ FAR 4812 AS1530.4
  3M Duct Wrap 615+ CSIRO FCO-3273 AS1530.4
