Metal pipes (steel, copper, continuous insulation) through a concrete wall, min 100mm. Max FRR -/120/120. Does not require annular space. Click here for Tested System Tech Drawing
System ID #: 406
Max Fire Rating: 120
Max Thermal Rating: 120
Size: Steel to 324mm, Copper to 54mm
