AGNI-Seal Shaftwall Copper or Steel Pipe

Copper or steel pipe (32mm - 100mm) through a Shaftwall (25mm Shaftliner and 16mm FR plasterboard). AGNI-Seal to depth of wall with AGNI-Shield wrap. Max FRR -/60/60.

Products

Details

System ID #: 231
Max Fire Rating: 60 minutes
Max Thermal Rating: 60 minutes
Size: Copper or steel pipe 32mm-100mm

Build specifications

Add to specification

Downloads

Below are the downloads available. Please tick the ones you would like to receive and complete your details and select how you would like the files delivered to you. Alternatively you can click on the individual download name to view it now.

  Select All
  System diagram
  FC231 AGNI-Seal Shaftwall Copper or Steel Pipe Tech Drawing
  AGNI-Seal Technical Data Sheet
  AGNI-Shield Technical Data Sheet
